WisLink PLC LX200V50 – Power Line Communication (PLC) Module

High-performance PLC module based on Qualcomm QCA7550 with 1000 Mbps data rate, 128-bit AES encryption, and HomePlug AV2 support. Ideal for HD multimedia streaming, smart home, and industrial IoT over existing power lines.

SKU: 500020

59,00 €

excl. 19% VAT plus Shipping Costs

Product Description Technical Details

The WisLink PLC LX200V50 is an advanced Power Line Communication (PLC) module built around the Qualcomm QCA7550 SoC, designed to bridge multi-stream Ethernet content from a power line network into a standard 802.3 Ethernet network — without requiring any user configuration.

Delivering a maximum physical data rate of 1000 Mbps, this module is ideal for high-bandwidth applications such as HD video streaming, smart home automation, and industrial IoT. Its integrated MAC layer manages network access and service flows to ensure optimal Quality of Service (QoS) across the power line medium.

The LX200V50 features 128-bit AES link encryption, supports multiple HomePlug® AV2 profiles (MIMO and SISO), and uses advanced modulation up to 4096-QAM. It supports 2×2 MIMO with beamforming, robust Turbo Code FEC, automatic channel adaptation, and enhanced noise mitigation via patented line synchronization techniques.

The module can network with up to 8 units and is fully compliant with IEEE 1901, IEEE 1905.1, and HomePlug AV standards. Designed with 16 MB internal DDR2 memory, it includes built-in IGMP multicast support and hardware packet classification for prioritized traffic.

Plug-and-play capability meets powerful PLC performance for next-generation connected systems.

Technical Specification Details
Model WisLink PLC LX200V50
SoC Qualcomm QCA7550
Max Data Rate 1000 Mbps
Encryption 128-bit AES Link Encryption with key management
Networking Capability Up to 8 modules
Memory 16 MB DDR2
modulation OFDM: 4096/1024/256/64/16/8-QAM, QPSK, BPSK, ROBO, HS-ROBO, Mini-ROBO
MIMO Support Line-Neutral / Line-Ground 2×2 MIMO with beamforming
Frequency Range Up to 67 MHz (below CATV interference)
Error Correction Turbo Code FEC, Decoder Rates: 1/2, 16/21, 8/9
MAC Layer HomePlug AV2 compliant, CSMA/CA priority-based access, IGMP multicast support
Quality of Service (QoS) Hardware packet classifiers for ToS, CoS, and IP port prioritization
Power Save Mode Supported
Compliance IEEE 1901, IEEE 1905.1, HomePlug AV, HomePlug AV2
OFDM Technology Windowed OFDM with noise mitigation and dynamic channel adaptation
