PWM Expansion Module NXP PCA9685 – RAK13004
The RAK13004 is a WisBlock PWM expansion module based on the NXP PCA9685 chip, providing up to 16 PWM outputs for precise LED brightness control. Perfect for RGB LEDs, status indicators, and LED displays.
6,00 €
excl. 19% VAT plus Shipping Costs
Product Description
Technical Details
The RAK13004 PWM Expansion Module adds up to 16 independent PWM outputs to your WisBlock solution. Powered by the NXP PCA9685 chip, it communicates via a 1 MHz Fast-mode Plus compatible I²C interface.
With 4096 programmable brightness levels (12-bit), the module enables fine-tuned LED brightness control. The output frequency typically ranges from 24 Hz to 1526 Hz, making it suitable for a variety of applications including RGB or RGBA LED drivers, status indicators, and LED display panels.
The RAK13004 supports hot insertion, offers low standby current, and accepts an operating voltage of 2.3 V to 5.5 V, all while functioning within a wide -40 °C to +85 °C temperature range. Measuring only 25 × 35 mm, it is a compact and versatile expansion for modular IoT projects.
| Specification | Details |
|---|---|
| Model | RAK13004 PWM Expansion Module |
| Chipset | NXP PCA9685 |
| PWM Outputs | 16 (LED driver connectors) |
| Brightness Control | 4096 steps (12-bit) linear programmable per LED |
| LED Output Frequency | 24 Hz to 1526 Hz |
| Interface | I²C, 1 MHz Fast-mode Plus compatible |
| Special Features | Hot insertion, Low standby current |
| Operating Voltage | 2.3 V to 5.5 V |
| Power Supply | 3.3 V via WisBlock Core module |
| Operating Temperature | -40 °C to +85 °C |
| Dimensions | 25 × 35 mm |
| Applications | RGB/RGBA LED drivers, LED status indicators, LED displays |
