NB-IoT LTE CAT M1 Quectel BG77 – RAK5860

The RAK5860 module is based on the Quectel BG77, supporting LTE Cat M1 and LTE Cat NB2 cellular IoT protocols. With integrated GNSS for GPS and GLONASS, it provides a reliable and low-power solution for IoT devices, even in areas without WiFi or LoRaWAN® coverage.

SKU: 110005

30,00 €

excl. 19% VAT plus Shipping Costs

Product Description Technical Details

The RAK5860 NB-IoT / LTE-M Module brings cellular IoT connectivity to the WisBlock system, powered by the Quectel BG77 chipset. Supporting LTE Cat M1 and LTE Cat NB2, it is the ideal choice when your LoRa® application requires cellular access in regions lacking WiFi networks or LoRaWAN® gateways.

The module features integrated GNSS functionality (GPS and GLONASS) for accurate location services. Programming is straightforward using the Quectel AT command set, with communication via UART directly to a WisBlock Core module.

Designed for battery-powered applications, the RAK5860 can be fully powered down within the WisBlock system to minimize energy consumption. It includes IPEX connectors for external LTE and GPS antennas and supports both Nano-SIM and eSIM options.

Package Inclusion:

  • 1x RAK5860 Module

  • 1x LTE Antenna

  • 1x Active GPS Antenna

Possible Applications:

  • IoT solutions in areas without LoRaWAN or WiFi coverage

  • Gateway between LoRa® nodes over LTE

  • Asset tracking with GNSS location

  • Smart agriculture and environmental monitoring

  • Industrial IoT systems with cellular connectivity

Specification Details
Module RAK5860 – NB-IoT LTE CAT M1 Module based on Quectel BG77
Chipset Quectel BG77
Supported Networks LTE Cat M1, LTE Cat NB2 (LTE-FDD, half-duplex)
GNSS Support GPS, GLONASS
Communication UART interface, AT command set
Debug/Log Port Micro-USB
Antenna Connectors IPEX connectors for LTE and GPS antennas
SIM Support Nano-SIM and eSIM options
Status Indicators LEDs for operating status
Power Supply 2.6 – 4.2 V (typical 3.3 V)
Dimensions 25 x 35 mm
Package Inclusion 1x RAK5860 Module, 1x LTE Antenna, 1x Active GPS Antenna
