Hall Sensor Texas Instruments DRV5056A4QDBZR – RAK12044

The RAK12044 Hall Sensor, based on the Texas Instruments DRV5056A4QDBZR, delivers precise magnetic field-based position sensing. With a digital I²C interface and high sensitivity, it is ideal for applications such as industrial automation, medical devices, game controllers, and fluid flow measurement.

SKU: 100209

8,00 €

excl. 19% VAT plus Shipping Costs

Product Description Technical Details

The RAK12044 Hall Sensor, part of the WisBlock Sensor Series, is a high-precision positioning sensor powered by the Texas Instruments DRV5056A4QDBZR. It responds proportionally to the magnetic flux density of a south pole.

Featuring 15 mV/mT sensitivity with a measuring range up to 155 mT, the RAK12044 ensures accurate and reliable data across a variety of applications. Its digital I²C interface allows easy integration with WisBlock Core modules for IoT solutions.

Compact in size (10 x 10 mm) and designed for 3.3 V power supply, the sensor operates reliably in temperatures ranging from -40 °C to +85 °C, making it versatile for industrial and consumer use.

Typical Applications:

  • Precise position sensing

  • Industrial automation and robotics

  • Home appliances

  • Gamepads, pedals, keyboards, and triggers

  • Height, tilt, and weight measurement

  • Fluid flow rate measurement

  • Medical devices

  • Current sensing

Specification Details
Module RAK12044 – Hall Sensor based on Texas Instruments DRV5056A4QDBZR
Chipset Texas Instruments DRV5056A4QDBZR
Measurement Principle Responds proportionally to the flux density of a magnetic south pole
Sensitivity 15 mV/mT, up to 155 mT range
Interface I²C digital
Power Supply 3.3 V
Operating Temperature -40 °C to +85 °C
Module Size 10 x 10 mm
Applications Position sensing, automation, home appliances, game controllers, tilt/weight measurement, flow measurement, medical devices, current sensing
