RAK12028 + RAK12031 Through-Beam Fork Sensor – Omron EE-SX1041 Module
The RAK12028 combined with the RAK12031 is a through-beam fork sensor based on the Omron EE-SX1041. It is ideal for precise measurement of speed and position, using code discs for motor control or linear code bars for movement tracking.
5,50 €
excl. 19% VAT plus Shipping Costs
3 in stock
Product Description
Technical Details
The RAK12028 + RAK12031 is a through-beam fork sensor from the RAKWireless WisBlock Sensor series, powered by the Omron EE-SX1041.
-
The RAK12028 serves as the connector module, featuring one standard WisBlock sensor connector for integration with the WisBlock Base and a 6-pin connector to link the RAK12031 via cable.
-
The RAK12031 is the fork sensor module, capable of reliably detecting small moving objects. With a slot width of 5 mm and a slot depth of 8.2 mm, it is well-suited for applications that require motor speed measurement using code discs or linear motion tracking with code bars.
The package includes a rectangular cable, making the system a ready-to-use solution for motor control, movement detection, and IoT-based automation applications.
| Specification | Details |
|---|---|
| Chipset | Omron EE-SX1041 |
| RAK12028 Module Size | 10 x 10 mm |
| RAK12031 Module Size | 15 x 25 mm |
| Slot Width (RAK12031) | 5 mm |
| Slot Depth (RAK12031) | 8.2 mm |
| Function | Detects small moving objects; measures velocity and position using grating or code discs |
| Additional Module Required | RAK12031 must be connected to RAK12028 |
| Connectors | 1x Standard WisBlock Sensor Connector; 1x 6-Pin Connector for RAK12031 |
| Package Contents | 1x RAK12028 Module, 1x RAK12031 Module, 1x Rectangular Cable |
