Milesight LoRaWAN Controller IP67 Multi I/O Modbus with Solar Panel UC502-NO3GL NB-IoT/Cat.1
The Milesight UC502-NO3GL is a robust LoRaWAN® multi-interface controller featuring Modbus RTU, RS232/RS485, SDI-12, analog inputs, GPIO, optional NB-IoT/Cat.1 connectivity, and an integrated solar panel. With an IP68 enclosure, three long-life ER26500 batteries, and wide temperature tolerance, it is ideal for long-term outdoor IoT deployments such as Smart Agriculture, environmental monitoring, industrial sensing, and remote automation.
156,90 €
excl. 19% VAT plus Shipping Costs
2 in stock
Related items
RAKwireless WisGate Edge Pro Outdoor LoRaWAN Gateway Rak7289cv2 (8 Channel) LTE
SKU: 715123 401,00 €3 in stock
Grand total: 0,00 €
Product Description
Technical Details
The Milesight UC502-NO3GL NB-IoT/Cat.1 is a highly capable LoRaWAN® Multi-I/O Controller with added cellular (NB-IoT/Cat.1) connectivity for hybrid communication environments. It provides a broad set of industrial and environmental sensor interfaces, including GPIO, RS232/RS485, 2 × 12-bit analog inputs, and SDI-12, making it suitable for complex monitoring and automation tasks.
The two GPIO ports can be configured via software as digital inputs, digital outputs, or pulse counters, allowing integration with flow meters, relays, switches, and alarm sensors. The high-resolution 12-bit analog inputs support 4–20 mA and 0–10 V signals, enabling connection to industrial-grade transducers and environmental probes. The RS232/RS485 interface supports transparent mode and Modbus RTU, ensuring compatibility with SCADA systems and industrial controllers.
The SDI-12 interface enables seamless integration of professional environmental sensors such as soil moisture, hydrological, and meteorological devices.
The device communicates via LoRaWAN® OTAA/ABP Class A and additionally supports NB-IoT/Cat.1, offering highly reliable data transmission even in challenging or remote locations. Configuration is fast and convenient through NFC, USB-C PC software, or remote downlink commands.
The UC502-NO3GL features three 9000 mAh ER26500 Li-SOCl₂ batteries, combined with a 6 V / 1.7 W integrated solar panel, guaranteeing extremely long operating times for fully off-grid installations. An additional DC 5–24 V input provides optional external power. The IP68 enclosure protects the device against water, dust, and extreme outdoor environments, with an operating temperature range of –30°C to +70°C.
Advanced features include threshold alarms, change alarms, local storage for 600 entries, data retrievability, and data retransmission to ensure data integrity in unstable network conditions.
Typical applications include:
– Environmental monitoring (weather, water level, air quality, soil sensors)
– Smart Agriculture and irrigation automation
– Industrial IoT monitoring and SCADA integration
– Water, energy, and flow metering
– Remote telemetric systems
– Long-term autonomous field installations
| Category | Technical Details |
|---|---|
| Wireless Protocol | LoRaWAN®, NB-IoT/Cat.1 (depending on model) |
| Antenna | Internal or external antenna optional; EA version: 1 × 50 Ω SMA Female Connector |
| Frequency Bands | CN470, IN865, EU868, RU864, US915, AU915, KR920, AS923-1/2/3/4 |
| Tx Power | 16 dBm (868 MHz), 20 dBm (915 MHz), 19 dBm (470 MHz) |
| Sensitivity | -137 dBm @ 300 bps |
| Work Mode | UC501: OTAA/ABP Class A & Class C; UC502: OTAA/ABP Class A |
| Interface Type | M12 A-Coded Male |
| GPIO Ports | 2 × GPIO (Digital Input, Digital Output, Pulse Counter – software switchable) |
| Logical Level | Low: 0–0.8 V; High: 2.5–3.3 V |
| Maximum Current | 20 mA |
| Recommended Input Frequency | ≤ 4000 Hz |
| Serial Port | 1 × RS232 or RS485 (software switchable) |
| Baud Rate | 1200–115200 bps |
| Serial Protocols | Transparent (RS232/RS485), Modbus RTU (RS485) |
| Analog Inputs | 2 × Analog Input; 12-bit resolution; 4–20 mA or 0–10 V (switchable) |
| SDI-12 Interface | 1 × SDI-12; SDI-12 V1.4 (transparent) |
| Power Outputs | 2 × 3.3 V, 2 × 5/9/12 V (switchable); continuous (3.3 V) or 0–10 minutes (5/9/12 V) |
| Button | 1 × Internal Power/Reset Button |
| USB Interface | 1 × USB Type-C (internal) for configuration and console |
| LED Indicator | 1 × Internal Reboot/Reset LED |
| Power On & Off | NFC Mobile App, PC Software via USB-C, internal power button |
| Configuration | NFC Mobile App, PC software via USB-C, Downlink |
| Advanced Features | Threshold Alarm, Change Alarm, Multicast (UC501 only), 600 data entries, data retrievability, data retransmission |
| Power Supply | UC502-NO3GL: – 3 × 9000 mAh ER26500 Li-SOCl₂ batteries – 6 V / 1.7 W solar panel – DC 5–24 V input |
| Operating Temperature | -30°C to +70°C |
| Relative Humidity | 0–95% (non-condensing) |
| Ingress Protection | IP68 (1 m underwater for 7 days) |
| Dimensions | 116 × 116 × 45.5 mm |
| Installation | Wall or Pole Mounting |
| Certifications | CE, FCC, ISED; RoHS compliant |
